2-Post Short (Wide)
Features
- Single hydraulic lifting cylinder direct drive
- Multiple parking heights
- Faster Lifting Speed Than Other two Post Lifts
- 100% Laser cutting process for all parts and the whole structure
- Preassembled parts for easy installation
- Effortless Disassembly and Relocation
- Safety key switch controller
- Hydraulic overload protection
- Anti-skid ramp and platform
- Anti-rust smooth powder coating finishing
- Enhanced anti-corrosion galvanized waving plates
- 5-Year Warranty on parts, 1-Year Warranty on labor
- Posts Can Be Shared for Multiple Parallel Lifts
Safety System
- Full Range Anti-Fall Locks
- Limit Switches
- Emergency Stop Button
- Photocell Sensor
- Lock Down Button
- APPLICATION SCENARIOS
- PARAMETERS
Description
| Vehicle Model | Sedan, regular SUV |
| Foundation | C25-C30, thickness > minimum 4 Inches, suggested 6 Inches |
| Ceiling Height | 153 1/2 Inches (Sedan+SUV) / 169 1/4 Inches (2 SUVs) |
| Buildings | Residential or Storage |
| Environment | Indoor/Outdoor (Outdoor protection devices available) |
 |
Model | SAL-2PSW |
![](https://stakautolifts.com/wp-content/uploads/2024/05/car-lit.png") |
Lifting Capacity | 7,055 lbs |
| A – | Vehicle Width | 90 1/2″ |
| B – | Base Width | 94 1/2″ |
| C – | Mid Width | 101 1/2″ |
| D – | Overall Width | 107 1/2″ |
| E – | Front Post Offset | 32″ |
| F – | Overall Length (side) | 155″ |
| G – | Overall height (side) | 119″ |
| H – | Upper Vehicle Clearance | 72″ |
| I – | Lower Platform Height | 83″ |
| J – | Base Length | 68″ |
| K – | Post Offset (top) | 32″ |
| L – | Top of Overall Width | 90 1/2″ |
| M – | Top of Overall Length | 107 1/2″ |
 |
Vehicle Height | Up to 80″ |
 |
Vehicle Width | Up to 87 1/2″ |
 |
Vehicle Length | < 197″ |
 |
Control Box | Integrated modules for simple writing |
 |
Power Unit | 2.2 kW Hydraulic |
 |
Electrical Requirements | 120V, 1 phase |
 |
Parking Time | 45-55 Seconds |
*Most parameters can be customized based on your requirements.
